Technical Data Sheet: APW-S4020-A15-B-DXACWZ Waterjet Stone Cutting Machine
When selecting a high-performance stone cutting machine, one of the most important reference tools is the technical data sheet. This document details every aspect of the system’s capabilities—from dimensions and power ratings to accuracy, pressure, and cutting speed—helping users match the equipment to their specific application.
The APW-S4020-A15-B-DXACWZ is a flagship model by APW, designed for heavy-duty, high-precision cutting of stone materials such as granite, marble, slate, and engineered stone. Below, we break down the core technical specifications that define this system’s advanced performance.
Cutting Platform Specifications
| Specification | Details |
|---|---|
| Model | APW-S4020-A15-B-DXACWZ |
| Structure Type | Optimized Gantry (Bridge) |
| X Axis Travel | 4000 mm |
| Y Axis Travel | 2000 mm |
| Z Axis Travel | 150 mm |
| Drive Type | AC Servo |
| Cutting Accuracy | ±0.02 mm |
| Max Cutting Speed | <3 m/min |
| Max X/Y Axis Speed | 10 m/min |
| Max Z Axis Speed | 1 m/min |
| Table Material | Stainless Steel |
| Table Thickness | 3 mm |
| Load Capacity | 1000 kg/m² |
| Total Power | <6.79 HP / 5 kW |
| Power Supply | AC 220V, 50/60Hz |
Pump & 5-Axis Cutting Head
| Specification | Details |
|---|---|
| Main Motor Power | 37 kW |
| Max Working Pressure | 420 MPa |
| Continuous Pressure | 380 MPa |
| Max Water Flow | 3.7 L/min |
| Abrasive Orifice Sizes | 0.26 mm, 0.30 mm, 0.33 mm |
| Z Axis Travel | 150 mm |
| A Axis Tilt | ±89° |
| C Axis Rotation | ±180° |
| B Axis Tilt | 0° |
| Power Supply for Pump | 380V, 3-phase, 50Hz |
| Noise Level | 75 dB(A) |
| Pump Size (L×W×H) | 715 × 1045 × 1272 mm |
| Pump Weight | 1100 kg |
Control System & Automation
| Specification | Details |
|---|---|
| Control Platform | NC-Studio |
| Software Features | CAM, NC Editor, Multi-point Z-height detection, Visual contour extraction, Edge-finding, Barcode reader |
| Abrasive Feeding Capacity | 270 kg |
| Inlet Pressure | 0.2–0.8 MPa |
| Operating Air Flow | 0.5 m³/min |
| Self-Sealing & Air Valve | Yes |
| Power Supply (Control) | GC 24V |
Stone Cutting Advantages with S4020’s Technical Precision
Stone is one of the hardest and most beautiful natural materials—but also one of the most challenging to cut. The technical data sheet for the S4020 model reveals why it excels in this area: for the S4020 model reveals why it excels in this area:S4020型号的（相关内容）揭示了它在这方面表现出色的原因：
- Cold Cutting with High Pressure: No thermal deformation or discoloration of stone surfaces
- Complex 3D Cuts: Thanks to ±89° and ±180° axis control
- Large Format Capability: 4000 × 2000 mm coverage fits full-size slabs
- Strong Load Handling: 1000 kg/m² table load for dense stone blocks
- Smart Control: CAM software, contour tracking, and abrasive flow automation increase cutting efficiency
These capabilities enable the S4020 to serve industries ranging from high-end architecture and interior design to industrial stone fabrication and monument production.
Applications Based on Technical Performance
Given its specifications, the APW-S4020 is ideal for:
- Granite countertop shaping
- Marble floor inlays and medallions
- Slate and quartz panel cutting
- Decorative stone engraving
- Stone tile chamfering and beveling
It performs especially well in custom fabrication environments where precision, repeatability, and speed must coexist.
Let the Data Guide Your Stone Cutting Investment
The APW-S4020-A15-B-DXACWZ isn’t just a stone cutting machine—it’s a data-driven platform for reliable, industrial-grade performance. The technical data sheet reveals everything a serious buyer needs to evaluate: travel distances, cutting angles, pressure ratings, material support, software intelligence, and automation readiness. reveals everything a serious buyer needs to evaluate: travel distances, cutting angles, pressure ratings, material support, software intelligence, and automation readiness.
If your operation depends on high accuracy, low waste, and versatility in working with stone, the S4020 is a strategic investment that aligns performance with measurable results.
